OUR CAPABILITIES

Integrated Manufacturing.
From Raw Material to Finished Component.

OREX delivers fully integrated manufacturing capabilities under one roof, combining forging, heat treatment, precision machining and electroplating into a seamless production ecosystem. Every process is engineered to ensure metallurgical integrity, dimensional precision and complete traceability from raw material to finished component.

Open Die Forging

Forging

Open die forging, ring rolling and custom shaping for high-integrity components.
Heat Treatment

Heat Treatment

Controlled thermal processing for optimized mechanical properties.
Precision CNC Machining

CNC Machining

Precision turning and machining with high accuracy and repeatability.
Electroplating

Electroplating

Surface finishing for corrosion resistance and extended component life.

Forging

From open-die forgings to precision rolled rings, OREX manufactures high-integrity forged components engineered for critical industrial applications. Every forging is produced with controlled grain flow, optimized material properties and dimensional consistency to meet demanding customer requirements.

Rings
Up to Ø1200 mm
Shafts
Up to 2 metre Length · Up to 1 Tonne
Rectangular Bars
Up to 2 metre Length · Up to 2 Tonnes
Open Die Special Forgings
Up to 500 kg
2500 Kg Forging Furnace
MakeAQZ
Temperature1300°C
Capacity2500 Kg
Blower, Burner & Pumping Unit
1000 Kg Forging Furnace
MakeAQZ
Temperature1300°C
Capacity1000 Kg
Blower, Burner & Pumping Unit
Open Type Pneumatic Hammer
MakeSKHE
Blank Capacity1000 Kg
Shaft Capacity2500 Kg
Standard Fittings
DY 600E Ring Rolling Machine
MakeWUXI
Rolling Range200 – 1350 mm
Capacity2500 Kg
Conventional Ring Rolling Machine
MakeSKHE
Rolling RangeØ119 – Ø330 mm
6½ Feet Lathe
MakeDynamic
Power3 HP
RPM600 RPM
RangeØ10 – Ø800 mm
2 Machines
12½ Feet Lathe
MakeJohn Lang & Sons Ltd
Power10 HP
RPM600 RPM
Max DiameterUp to Ø1200 mm
7½ Feet Lathe
MakeKrish
Power3 HP
RPM600 RPM
RangeØ10 – Ø800 mm
7½ Feet Lathe
MakeMysore Kirlosker
Power3 HP
RPM600 RPM
RangeØ10 – Ø400 mm
Ø205 Band Saw Machine
MakeLaxson
4 Machines
20 KL Vertical Air Receiver Tank
15 KL Vertical Air Receiver Tank
ELGI Screw Compressor
Power75 KW
ELGI Screw Compressor
Power45 KW
TIG / ARC Welding Machine
Drilling Machine
Grinding Wheel Machine
Cutting Wheel Machine

Heat Treatment

Controlled heat treatment processes enhance mechanical properties, improve wear resistance and ensure optimum performance for demanding industrial applications.

Annealing
Normalising
Oil Quenching
Water Quenching
Tempering
Double Tempering
Maximum Batch Weight
2000 Kg
Heat Treatment Furnace
MakeFLUXO
Capacity2.0 Tonnes
Quenching Tank
Capacity42000 Litres

Precision CNC Machining

Modern CNC turning centres and vertical turning lathes deliver high dimensional accuracy and repeatability for critical machined components across multiple industries.

Maximum Diameter
Ø1100 mm
Maximum Component Weight
500 Kg
VTL40 Vertical Turret Lathe
MakeACE
ChuckØ800 mm
Swing1050 mm
DX350 CNC Turning Centre
MakeJothi CNC
ChuckØ305 mm
Length700 mm
2 Machines
TL250 CNC Turning Centre
MakeLML
ChuckØ250 mm
Length350 mm
3 Machines
TL30 CNC Turning Centre
MakeLML
ChuckØ250 mm
Length350 mm
TL200 CNC Turning Centre
MakeLML
ChuckØ165 mm
Length250 mm
6 Machines
Hydraulic Marking Machine
Rockwell Hardness Tester
½ Inch Pillar Drilling Machine
2 Machines
Manual Stacker
Capacity1000 Kg

Electroplating

Surface finishing processes provide corrosion resistance, enhanced durability and long-term performance for critical industrial components.

Hexavalent Yellow
Trivalent Blue
Maximum Ring Size
Up to 2 Metres
Electro Plating A.C Rectifier
MakeGanesh Electricals
Rating4000 A
2 Units
Transformer
MakeGanesh Electricals
Rating12 KVA
2 Units
Complete Plating Equipment
Process7 Tank Process
Lines2 Independent Processing Lines
Maximum Component Height
Up to 2 Metres
Dedicated Plating Tools & Equipment
